Beocord 5500 sticking drawer

7 replies
I snapped up a Beocord 5500 from eBay recently and was pleasantly surprised by the condition - it plays and records well (it didn't even need new tape belts) and is in good cosmetic condition. However I am having trouble with the drawer.  It does work but is very sluggish and sticks sometimes.  If I put my turntable on top of it, the weight seems to stop the drawer being able to open and close at all without encouragement.  It does make a bit of a metal-on-metal noise when it is opening and closing too. The drawer belt was a bit loose so I replaced it with a better one, but it hasn't really made any difference; it still sticks, especially when my turntable is on top of it. It actually comes apart quite easily and I've had a good look around inside but there is nothing obviously wrong.  The drawer opens and closes much more smoothly when the cover is off, but still not quite as well as I thank it should. So, some oiling, or greasing maybe? Does anyone have any experience of this problem and could offer me some advice? I'd be very grateful if you do.

Location: Liverpool

My B&O Icons:

BeoCenter-9500.png BeoCenter-9500.png
Beoremote-Beo4.png Beoremote-Beo4.png
Beovox.png Beovox.png
Beovision-11.png Beovision-11.png
Beotime.png Beotime.png
Beosound.png Beosound.png
Beosound-Moment.png Beosound-Moment.png
Beosound-9000.png Beosound-9000.png
Beosound-5.png Beosound-5.png
Beosound-4.png Beosound-4.png
Beoremote-One.png Beoremote-One.png
Beoplay-Portal.png Beoplay-Portal.png
Beoplay-EX.png Beoplay-EX.png
Beoplay-Earset.png Beoplay-Earset.png
Beoplay-A2.png Beoplay-A2.png
Beogram-400x.png Beogram-400x.png
Old enough to have gazed at classic B&O HiFi in Plumbs shop windows in the 80s...
Check the metal braces on the underside of the upper cover. The plastic "rivets" that connect the brace to the cover can fail. This lets the cover interfere with the drawer. Also check the screw for mounting the drawer motor. This can rub if the drawer rollers have settled. Glitch
It's not uncommon to see the Beocords rubber feet missing as they harden with age. The outer parts break off, while the inner parts fall inwards where they will often get stuck between the Beocords bottom plate and the drawer, causing a braking effect. Look in from the front with a torch light. Martin
Brilliant thank you - both of those checked, the rivets look okay but you were right about those rubber feet Dillen - I managed to pry the bits out and it's now opening and closing fully, even with the Beogram on top of it. It's still a bit noisy so I think I'll open it up and see if there are any other bits of hardened rubber still lingering.

Location: Liverpool

My B&O Icons:

BeoCenter-9500.png BeoCenter-9500.png
Beoremote-Beo4.png Beoremote-Beo4.png
Beovox.png Beovox.png
Beovision-11.png Beovision-11.png
Beotime.png Beotime.png
Beosound.png Beosound.png
Beosound-Moment.png Beosound-Moment.png
Beosound-9000.png Beosound-9000.png
Beosound-5.png Beosound-5.png
Beosound-4.png Beosound-4.png
Beoremote-One.png Beoremote-One.png
Beoplay-Portal.png Beoplay-Portal.png
Beoplay-EX.png Beoplay-EX.png
Beoplay-Earset.png Beoplay-Earset.png
Beoplay-A2.png Beoplay-A2.png
Beogram-400x.png Beogram-400x.png
Old enough to have gazed at classic B&O HiFi in Plumbs shop windows in the 80s...
Did you manage to get rid of the noisyness? Was there any other rubber inside?
Sorry just saw this.  I did - a good clean up inside, and I added a very small amount of watch oil to the runners of the drawer, and to the spindle of the wheel that drives the drawer belt.  It did reduce the nose considerably.

Location: Liverpool

My B&O Icons:

BeoCenter-9500.png BeoCenter-9500.png
Beoremote-Beo4.png Beoremote-Beo4.png
Beovox.png Beovox.png
Beovision-11.png Beovision-11.png
Beotime.png Beotime.png
Beosound.png Beosound.png
Beosound-Moment.png Beosound-Moment.png
Beosound-9000.png Beosound-9000.png
Beosound-5.png Beosound-5.png
Beosound-4.png Beosound-4.png
Beoremote-One.png Beoremote-One.png
Beoplay-Portal.png Beoplay-Portal.png
Beoplay-EX.png Beoplay-EX.png
Beoplay-Earset.png Beoplay-Earset.png
Beoplay-A2.png Beoplay-A2.png
Beogram-400x.png Beogram-400x.png
Old enough to have gazed at classic B&O HiFi in Plumbs shop windows in the 80s...
I too have drawer issues with a Beocord 6500. Just thought I would add that on mine the drawer tyres have hardened and become elliptical - I guess from where the Beocord has sat in one position for a long time. This will no doubt have an effect on how hard the drawer motor has to work and how smooth the action will be. I bought a replacement set of tyres from Beoparts (now: Danish Sound Parts) and shall fit them soon. The obligatory write-up will follow in due course.

Location: Kent, UK

My B&O Icons:

BeoCenter-9500.png BeoCenter-9500.png
Beoremote-Beo4.png Beoremote-Beo4.png
Beosound.png Beosound.png
Beoplay-H3.png Beoplay-H3.png
Beomaster.png Beomaster.png
Beofan for many years with a penchant for 1990s audio systems.
