BeoMaster 5 and A.AUX

9 replies
MA
Madskp
Gold
1759 posts
Posted March 1, 2023 at 14:21 GMT
#699345
we are experimenting with alternative use of some of B&O's "black boxes". We have confirmed that a combination of the 1611 Beolink converter and the MCL2AV can give access to two inputs (tape and CD) on the MCL2AV from a Beolab 2000, Beolab 3500 and from a masterlinked TV. However we haven't had the chance to confirm if this also will work from a Masterlinked Beosound/Beomaster. The setup would look something like this: BM5 -ML- 1611 -7 pin Datalink- MCL2AV - Beogram/Beocord
Millemis
Millemis
Bronze
1330 posts
Posted March 1, 2023 at 16:04 GMT ? Edited March 1, 2023 at 16:06 GMT
Right! However, the easiest way would be to use one of these: Please notice that Steve is only shipping to the UK for time being - but the Behringer can be bought elsewhere….just do a search for it. And…..if you want to connect more than one device, you’d need some kind of switch too. As for the 2nd question - I remember back in the days, that I had a stock external USB drive connected….so yes that should work! I would however, not recommend it - it will be much easier to use a PC/Mac for this, because you will have to tag the files properly in order to have these searchable and showing coverpics etc on the BS5. MM

Location: Flensborg————Danmark

MA
Madskp
Gold
1759 posts
Posted March 1, 2023 at 16:30 GMT
#699348

Location: Denmark

TB
tb59427
Bronze
103 posts
Posted March 1, 2023 at 17:50 GMT
...
The setup would look something like this: BM5 -ML- 1611 -7 pin Datalink- MCL2AV – Beogram/Beocord
Yeah, I've been following this thread with a mixture of amusement, fascination and sheer respect for the amount of knowledge present in this community. I have started to put out searches in ebay classifieds to see whether I can source the components at reasonable prices to also build such a setup.
TB
tb59427
Bronze
103 posts
Posted March 1, 2023 at 17:52 GMT
As for the 2nd question – I remember back in the days, that I had a stock external USB drive connected….so yes that should work! I would however, not recommend it – it will be much easier to use a PC/Mac for this, because you will have to tag the files properly in order to have these searchable and showing coverpics etc on the BS5. MM
Thanks for both hints. Found my old USB CD drive and hooked to the Mac. Still works :-) So that should be easier. Agreed.
MA
Madskp
Gold
1759 posts
Posted March 1, 2023 at 18:59 GMT
…
The setup would look something like this: BM5 -ML- 1611 -7 pin Datalink- MCL2AV – Beogram/Beocord
Yeah, I’ve been following this thread with a mixture of amusement, fascination and sheer respect for the amount of knowledge present in this community. I have started to put out searches in ebay classifieds to see whether I can source the components at reasonable prices to also build such a setup. great to hear that orhers are also following our little black box adventure ? let us know if you needany input. one buying advice for the MCL2AV is try to get one with the original power supply to be sure it has the right polarity on the power connector
Guy
Guy
GoldModerator
4508 posts
Posted March 2, 2023 at 17:07 GMT ? Edited March 2, 2023 at 17:26 GMT
Although I haven't purchased one, I think it's the same adaptor but from Sino American.  If I needed one I would give it a try. Hence you may be able to search for the 'OnTop' model number of the EU (2-pin) MCL2AV adaptor and find similar. EDIT:  Other UK eBay hits (for A31530B) show what looks like the same adaptor, but the polarity of the output pins is reversed (the MCL2AV needs centre-negative) so you would need to be a bit careful!
andbe
andbe
Bronze
10 posts
Posted May 12, 2023 at 07:18 GMT
Good morning together, my BeoMaster5 has not been in standby mode for quite some time. The BM5 is linked to BS5 and BL 8000. What strikes also the tracer is not functioned for switching off and turning on at the back any more. Is this a software or hardware issue that the board is defective. Also have already tested different options via the F8 key with connected keyboard at restart, but came to no result. Does anyone have any advice on what it might be? Thank you in advance greeting Andreas
BE
Beogrump
Bronze
2 posts
Posted May 6, 2024 at 20:08 GMT
#687308
Hi B&O lovers, Using a Beomaster 5 connected to a Beosystem 3 via ML in a BV9. I want to attach a separate CD player to the Beomaster 5 via USB / AUX cables with the Behringer UFO0202, so my questions are: 1, Can I invoke the A.Aux from the Beomaster 5 without a Besound5 attached? 2, Is it possible to replace the 'Web' selection option from the native Beomaster 5 menu with A.Aux? Would appreciate any help from budding developers or long term owners who have achieved something similar. Thanks A
