Beomaster 7000 FM Offset

5 replies
filip_kbh
filip_kbh
Bronze
332 posts
Posted August 10, 2023 at 04:22 GMT ? Edited August 10, 2023 at 04:39 GMT
#687882
Hi, I finally got my Beomaster 7000 back from repair. One thing that was not fixed (and it was my own fault as I changed the backup battery) is the FM offset. In the manual it says to shortcut 4TP1 two times but I am uncertain where it is. The picture in the Service Manual for BM7000 looks like this:   Do I need to unmount the board and remove the shield to get to the test point? Also, perhaps connected with the above, I do not get an RDS reading on my Beolink 7000 anymore. Or do you think this is a separate issue? It used to work.

Location: Copenhagen

filip_kbh
filip_kbh
Bronze
332 posts
Posted August 10, 2023 at 17:18 GMT ? Edited August 10, 2023 at 18:14 GMT
#703174
I managed to fix it. I had to remove the metal shield to get access to 4TP1 and short circuit it to ground. Now the frequencies are correct. RDS is still not working.

Location: Copenhagen

filip_kbh
filip_kbh
Bronze
332 posts
Posted August 10, 2023 at 19:15 GMT
#703177
Looking further in the Service manual, it says to carry out functions 16 and 7 in test mode which I have not done. Could that be the reason for RDS not working?

Location: Copenhagen

filip_kbh
filip_kbh
Bronze
332 posts
Posted August 14, 2023 at 18:01 GMT
#703249
Carried out functions 16 and 7. Everything reported back as functional with status 37. Still no working RDS. I guess I need to measure the 12 and 5 V connections to the RDS board first to see if it is actually getting power.

Location: Copenhagen

SI
siliconhillsaudio
Bronze
1 post
Posted November 26, 2023 at 05:48 GMT
#705505
Hello filip_kbh, Thank you for your posting! I am having the same FM offset issue with my BM7000 after the backup battery change. I plan to follow the instructions you outlined. Also, where can I find a Beomaster 7000 service manual PDF file? I have searched all of the usual web sources but can only find a schematic drawing. I do have a Beomaster 6500 and a copy of its service manual but the tuner board appears to be different. I appreciate any advice that you can pass along.
