Beovision 10-32 cannot find HDMI signal

Gab Kan

Bronze

6 posts

Posted November 16, 2025 at 19:51 GMT ? Edited November 16, 2025 at 19:53 GMT

Hi,
I just bought a BV 10-32 (Type 9541) in an auction and to my disappointment I cannot manage to get image feed from the HDMI connections.
I have never had a BV before so I am new to the setup. But I have read up as much as possible without success.Please help if you have experience or a clue of how to resolve this issue.
The screen seems to work, I can see the back light turning on and the B&O greeting when turning on the tv, the menu is visible and so are the names of the sources when changing source.
This far I have tried all 3 HDMI connections, with both my Tele2 dongle, a chrome cast unit from a Swedish television provider and my computer (Mac).
I tried setting both the computer and the dongle up as PC. I tried various other sources (dvd, v.mem, dtv) for both of them. The only difference I noticed was that I didn't get "static" from TV-source, when the dongle was plugged in.
The Mac does not detect the TV being connected as speaker or screen when connected though a HDMI cable.
My family is really happy with the beautiful TV and we would be grateful if we could keep it :•)
Any suggestions?

CharlieWednesday

Gold

670 posts

Posted November 16, 2025 at 20:14 GMT

#717068

I've never owned a BV10 but on the BV7 and BV8 (which I have owned), you need to tell the TV which HDMI socket is used for each input. In the BV7 or BV8 you would go to Menu, then Connections, then select one of the available AVs from the list. Once selected, you would choose which source that connection would respond to (V.Mem, PC, DVD and so on), and which HDMI socket it would use. Press OK/Play to save it, and it should work.

Location: Liverpool

My B&O Icons:

Old enough to have gazed at classic B&O HiFi in Plumbs shop windows in the 80s...

Ravsted

Bronze

458 posts

Posted November 16, 2025 at 20:27 GMT

#717070

Hi, This is how the menu is on my 10-40. Turn on TV: Beo4 TV Beo4: MENU Beo4: MENU (press again within few seconds) This gives a menu with 4 options. Choose 'øvrige muligheder' (other options) Choose 'tilslutning' (connections) This is where you 'map' a AV socket (e.g. a HDMI input) to a source button on the Beo4. I have AV1 mapped to DTV AV2 mapped to V.MEM AV3 to DVD So... Those 3 buttons on the Beo4 now select either of the 3 HDMI inputs. Hope it helps.

Guy

GoldModerator

4508 posts

Posted November 16, 2025 at 21:31 GMT

#717074

All the relevant BV10 documentation is available from B&O in various languages here:

Location: Warwickshire, UK

My B&O Icons:

Gab Kan

Bronze

6 posts

Posted November 16, 2025 at 21:57 GMT

#717076

Gab Kan

Bronze

6 posts

Posted November 16, 2025 at 21:58 GMT

#717077

Thanks for sharing, Guy. I've followed the instructions found in the manual. But no luck unfortunately…

Gab Kan

Bronze

6 posts

Posted November 16, 2025 at 22:16 GMT

#717078

I just wanted to add that I tried the HDMI cable with another device and it is working fine.

Ravsted

Bronze

458 posts

Posted November 16, 2025 at 22:50 GMT

#717079

Strange. I don't know if this can help somehow. I assume these are the correct 'terms' in English. My GUI is DK. Under Menu, menu, other options, connections, AV1 .... I got: Source: DTV Name: ...... IR: None HDMI: A S/P-DIF: None One more thing... Long shot. Under Menu, setup (4), other options, HDMI HDCP: On Pressing DTV changes to HDMI socket 'A' where I got a gen 2 Chromecast connected. Try power cycle the TV. Remove from mains in 10 mins.

Ravsted

Bronze

458 posts

Posted November 16, 2025 at 23:02 GMT

#717080

And another option... Try at own risk. Personally I never did such a reset. Others might know if this is a good idea. Press: TV Menu, menu You now got the menu with 4 options. Press Menu, 0, 0, GO (you need to be pretty quick) This will take you to the 'hidden' service menu. You can enter a menu item with 'GO' and leave with 'STOP' (on my non-joystick Beo4). Under 'settings' there is the option to 'reset all features'. Other who have tried can explain the consequences. I assume this will reset to factory settings.

Gab Kan

Bronze

6 posts

Posted January 13, 2026 at 09:28 GMT

#717611

I left the TV with a local BO repair man. Who diagnosed a faulty main board. I haven't spoken to him about the details yet but I guess it doesn't come as a big surprise as the HDMI connections are on the main board. Would you consider it worth looking for a functioning second hand pcb-14? Are they model specific? Best regards. Gab
