BV 10-46 -- install DVB-HD T/C/S2

8 replies

sverreh

Bronze

139 posts

Posted February 9, 2024 at 11:42 GMT ? Edited May 4, 2024 at 21:36 GMT

I have recently bought a BV 10-46 without the HD-module. From another 10-46 that was unrepairable, I have dismantled the DVB-HD T/C/S2 module. Is this a simple swap, og do I need som kind of software update? Are there any pitfalls I should be aware? My assumption is that this should be a fairly simple operation, but I would appreciate any comments or advice before I do the swap. I have found the service manual for a DVB_HD module for BS3, BV9 and BV7, but there are no service manual for the DVB-HD T/C/S2 module listed in the downloads section of Beoworld. In case anoyone have access to the latter I would appreciate a copy. Sverre

Location: Norway

My B&O Icons:

pepps

GoldModerator

481 posts

Posted February 10, 2024 at 20:42 GMT

#707499

I wish you the very best with this and will await your update. I don't have any knowledge or experience to share with you sadly, but I hope you succeed because this is something I've been looking into for my BV7.

Location: Kent, UK

My B&O Icons:

Beofan for many years with a penchant for 1990s audio systems.

Unknown Member (Imported)

Bronze

480 posts

Posted February 10, 2024 at 21:45 GMT

#707501

The 2 modules that is ”dvb receiver” is the same for all bv10/bv7/bsys3 its only different cables/cable lenght and brackets to mount them

RaMaBo

Gold

617 posts

Posted February 11, 2024 at 13:13 GMT ? Edited February 11, 2024 at 13:14 GMT

#707515

Hi This combination fits into also in the Beovision 8/40 (MK I and MK II) ;)

Location: Near Munich

My B&O Icons:

sverreh

Bronze

139 posts

Posted February 11, 2024 at 18:00 GMT

#707525

Thank you for the replies. After some reading I believe that any configuration can be done in the set-up menus once the module has been installed. I will report back when I have found the courage to perform the installation :)

Location: Norway

My B&O Icons:

sverreh

Bronze

139 posts

Posted February 12, 2024 at 22:15 GMT

#707561

Short version: Today I have a BV 10-46 with a fully functional DVB-HD module. Long version: Loosened the six screws and lifted off the front frame as described in the service manual. The marked panel had to come off. 13 T10 screws. The DVB-HD module. Two connectors, J7 and J18. I did not remember where they should be connected. I later discovered that a short RJ45 connection from the top of the card to the bottom connection panel had gone missing. Solved by inserting a short ethernet patch cable. It will be available should the need arise without having to dismantling the TV. Connector J 7 in the middle of the picture. The DVB module goes into the open space to the left of connector J7. When the picture was taken, I had yet to remove the blind lid in the bottom. Marked position for J 18. When everything was connected and re-assembled, I launched the service menu -- DVB service -- and changed DVB connected to YES. After a restart of the TV, all DVB-services I expected are now available to me. Sverre

Location: Norway

My B&O Icons:

pepps

GoldModerator

481 posts

Posted February 13, 2024 at 14:23 GMT

#707569

Woop! Woop! This has to go down as one of the best easy quick wins in Beoworld history!!

Location: Kent, UK

My B&O Icons:

Beofan for many years with a penchant for 1990s audio systems.

sverreh

Bronze

139 posts

Posted February 13, 2024 at 22:38 GMT

#707575

Indeed, fortunately no takers when I tried to sell the module some years ago. Best of luck with your BV7.
